Peerless-AV’s QSR Menu Board Mount is designed to create a seamless mounting surface through connecting wall plates. Continuous and fixed tilt options allow all displays to be tilted at the same angle with ease, creating a flawless alignment. The QSR Menu Board Mount allows for tool-less height adjustment and four-corner depth adjustment to alleviate issues with wall imperfections and fine-tuning. The kickstand feature holds the bottom of the display away from the wall during cable connection, reducing installation time and cost. Available in landscape and portrait design options, Peerless-AV offers a one-to-one ordering process, making the QSR Menu Board Mount the perfect mounting solution.

• Connecting wall plates create a continuous mounting surface– reduces installation time, reduces installation cost and eases display alignment
• Kickstand holds the display bottom away from the wall for ease of access during the cable connection installation process
• Quick connect latch automatically engages the wall plate when mounting the display for a speedy set up and peace of mind
• One to one ordering (order one mount for one display) – Simplifies the ordering and budgeting process
• Horizontal adjustment allows the installer to create a menu board with a seamless appearance
• Continuous and fixed tilt options (Increlok) assures that all displays are tilted at the same angle to assure alignment
• Included security hardware deters tampering and theft
• Open wall plate design reduces the chance of interfering with object on the wall
• Tool-less vertical adjustment on each universal display adapter bracket for post install leveling and height adjustment fine tuning
• Tool-less four corner depth adjustment aligns the displays on the same plane and helps alleviate issues with wall imperfections.

Product Specifications

• Minimum to Maximum Screen Size

  42" to 65"

• Weight Capacity

  100lb (45.5kg)

• Color

  Black

• Finish

  Powder Coat

• Distance from Wall

  2.84" (72mm)

• Increlock Increments

  0, +5, +10, +15

• Mounting Pattern

  550 X 400mm (15.75 X 15.75")

• Security Features

  Security Hardware

• Tilt

  +15/-0

• Product Dimensions

  22 X 19.48 X 3.09" (559 X 495 X 78mm

he Atdec TH-1040-VFM Telehook Wall Mount (Black with Silver) comes in a high quality finish, made of die-cast aluminum for low weight flat panel televisions, supporting VESA displays up to 55 lb. It lets you extend position and adjust pan as well as giving you the option to rotate the screen to landscape position. The TH-1040-VFM comes with integrated cable management while its ball point, in the display mounting head, allows for fine tilt and pan adjustment. Ships with a mounting plate that affixes to the wall, along with a bracket that attaches to the display.

Mount Basics

• Made from die cast aluminum
• Mount has 2 pivot points and a ball joint mechanism for adjustment and complete control over tilt, pan, and portrait to landscape rotation
• Smooth Glide thrust bearing technology allows the display to be moved smoothly and effortlessly, even with a heavy display
• Quick attachment / quick release mechanism installs and detaches display in seconds
• Mount comes pre-assembled for quick and easy installation, with advanced internal cable management
• Requires 1 stud for mounting

Conveniently install your video wall with the Peerless-AV DS-VW775 SmartMount Supreme Video Wall Mount. It supports 46 to 60" displays weighing up to 125 lb and extends from 3.9 to 14.02" from the mounting surface for easy access to the display's connectivity. 1.5" of adjustment along each axis allows precise leveling of your display. It supports 200 x 200 to 600 x 400mm VESA patterns. An optional quick release accessory releases your recessed display for service without pressing on the front of the display. The SmartMount Supreme supports displays in either portrait or landscape orientation.

VESA 200 x 200 to 600 x 400 compliant.

The SmartMount Supreme is a modular mount designed for near-unlimited video wall display configurations.

Security hardware option helps deter tampering and theft.

Integrated cable management allows cables to move in and out with the display.

The SmartMount Supreme accommodates displays in landscape and portrait orientation.

No tools required for micro-adjustment. The mount provides 1.5" of travel on each axis.

Reusable custom wall spacers are designed to eliminate guesswork and on-site installation calculations.

An optional quick release accessory releases a recessed display for service without pressing on the front of the display.

The wall plate is compatible with the Peerless-AV install app for a simplified installation.

DT Research

Product Line Research

Manufacturer DT Research

Packaged Quantity 1

Product Type Battery

Physical Characteristics Designed For Tablet

Compatibility Specs

DT Research DT301C, DT301S, DT311H, DT311Q, DT311SC, DT313Q ¦ DT Research Tablet DT313C ¦ DT Research Mobile Rugged Tablet DT311C, DT313C, DT313H ¦ DT Research Rugged Tablet DT301C, DT301S, DT301XC, DT311H, DT311SC, DT382GL

DisplayPort 1.4: The Basics

Released in March 2016, DisplayPort 1.4 brought some significant upgrades over its predecessor, DisplayPort 1.3. Here’s a quick rundown of what DisplayPort 1.4 has to offer:

• Higher Bandwidth: It supports a maximum bandwidth of 32.4 Gbps, allowing for higher resolutions and refresh rates.
• Resolution and Refresh Rates: With DP 1.4, you can achieve  title="GearIT 8K DisplayPort Cable - DP 1.4 Cable - 8K@60Hz / 4K@144Hz / 2K@165Hz, Braided">8K resolution at 60Hz or 4K resolution at 120Hz. This is a big deal for gamers and video editors who need sharp, smooth visuals.
• HDR Support: DisplayPort 1.4 includes support for HDR (High Dynamic Range), which enhances the contrast and color accuracy of your display. This is fantastic for watching movies, editing photos, or playing games with richer visuals.
• DSC 1.2: Display Stream Compression (DSC) 1.2 is a real game-changer. It allows for virtually lossless compression, meaning you can squeeze more data through the pipeline without noticeable quality loss.
• Forward Error Correction (FEC): FEC helps to reduce errors in data transmission, ensuring a more stable and reliable connection.

DisplayPort 1.4a: What’s New?

So, you might be wondering, what’s the difference between DisplayPort 1.4 and 1.4a? DisplayPort 1.4a, released in April 2018, is essentially an incremental update. The core specifications remain the same, but there are a few key enhancements:

• Improved HDR Support: DisplayPort 1.4a includes updates to better support HDR10+ and Dynamic HDR metadata, making it an even better choice for HDR content.
• Compliance Updates: 1.4a incorporates compliance updates and clarifications that help manufacturers develop more reliable products. This means better compatibility and performance across a wider range of devices.
