We are open to breaking this order into a smaller lot, but not into single pieces. (min 5)
System of Measurement |
Metric |
Bearing Type |
Roller |
Roller Bearing Type |
Needle |
For Load Direction |
Thrust |
Seal Type |
Open |
For Shaft Type |
Round |
For Shaft Diameter |
30mm |
ID |
30.04mm |
ID Tolerance |
0mm to 0.21mm |
OD |
47mm |
OD Tolerance |
-0.52mm to -0.13mm |
Thickness |
2mm |
Thickness Tolerance |
-0.01mm to 0mm |
Roller Material |
Steel |
Cage Material |
Steel |
Thrust Load Capacity, lbs. |
|
Dynamic |
3,650 |
Static |
15,700 |
Maximum Speed |
7,500 rpm |
Lubrication |
Required |
For Shaft Surface Smoothness (Ra) |
0.2 microns |
Temperature Range |
0° to 240° F |
Specifications Met |
DIN 5405-2 |
RoHS |
RoHS 3 (2015/863/EU) Compliant |
REACH |
Not Compliant |
DFARS |
Specialty Metals COTS-Exempt |
Country of Origin |
Germany |
Schedule B |
848240.0000 |
ECCN |
EAR99 |
