Item |
Radial Ball Bearing |
Bearing Type |
Open |
Single Row/Double Row |
Single Row |
Cage Material |
Steel |
Seal/Shield Type |
Open |
Lubrication |
MT47 Grease |
Static Load Capacity |
7,100 lb |
Dynamic Load Capacity |
12,400 lb |
Bore Tolerance |
+0/-.007mm |
Bearing Material |
Steel |
Max. RPM |
9,500 RPM |
Industry Number |
6309 JEM |
ABEC Tolerance |
1 |
Temp. Range |
-40 Degrees to 212 Degrees F |
Ball Material |
Alloy Steel |
Ring Material |
Alloy Steel |
Bearing Industry Number |
6309 |
Ring Material Grade |
100Cr6 |
Maximum Axial Load |
12,400 lbf |
Lubricant Material |
MT47 Grease |
Dynamic Radial Load Capacity |
55.3 kN |
Maximum Speed |
9,500 RPM |
Maximum Temperature |
212 Degrees F |
Minimum Temperature |
-40 Degrees F |
ABEC Rating |
1 |
Includes Retaining Ring |
No |
System of Measurement |
Metric |
Number of Rows |
One |
Retaining Ring Groove |
No |
Closure |
Open |
Static Radial Load Capacity |
31.5 kN |
Type |
Open |
